Fieldquip 3PL Compact Disc Harrows

100 Series Cat 1

  • 16ā€ disc with 7 Ā½ā€ disc spacing
  • 2ā€ square tube frame
  • 35 horse power range
  • 1ā€ square high carbon gang axles

200 Series Cat 1

  • 20ā€ discs 9ā€ disc spacing
  • 2 1/2ā€ square tube frame
  • 65 horse power range
  • 3ā€ x 2ā€ gang tubes
  • 1″ square high carbon gang axles

300 Series Cat 1 & 2

  • 22ā€ discs 9ā€ disc spacing
  • 3ā€ square tube frame
  • 95 horse power range
  • 4ā€ x 3ā€ gang tubes
  • 1 1/8ā€ square high carbon gang axles

All Models

  • Sealed, self-aligning ball bearings
  • Front gang adjust to 0°, 7°, 14°, 21° with adjustment handle
  • Rear gang adjust to 7°, 14°, 21° with adjustment handle

Specifications

Model100-3-01100-8-01200-6-01200-18-01300-10-01300-22-01
Working Width1.5m1.98m1.98m2.43m2.43m3.0m
Weight (Approx)230Kg315Kg333Kg430Kg565Kg640Kg
HP(Min)353565659595
No. Discs161620202024
FinishRed Powder CoatRed Powder CoatRed Powder CoatRed Powder CoatRed Powder CoatRed Powder Coat
