Specifications:
| Model No. | IF150 |
| Description | Infiller 150 |
| Working Width | 150 cm / 63” |
| Weight: | 1480kg |
| Tractor HP (min): | n/a |
Key Features:
Developed using the practical expertise of GKB’s contracting division, the Infiller has been thoroughly tried and tested to ensure user-friendly operation and reliable performance. The result is a well-engineered, purpose-built solution for consistent and efficient infill application.
Standard Build Includes: Specifications:
Dimensions (L x W x H):
250 x 175 x 230 cm / 99 x 69 x 91”
Transport Dimensions (L x W x H):
250 x 175 x 180 cm / 99 x 69 x 71”
Wheelbase: 150 cm / 59”
Bunker Capacity:
- Sand: 1.5 m³ / 53 ft³
- Rubber: 3 m³ / 106 ft³
- Cork: 4 m³ / 142 ft³
Tyres: Ø50 cm / Ø70 cm / Ø20” / Ø28”
Engine:
- Power: 24.7 hp / 18.2 kW
- Fuel: Diesel
- Cylinders: 4
- Engine Displacement: 1500 cc
- Max RPM: 2300 rpm
- Fuel Tank Capacity: 30 L
- Max Noise Level: 80 dB
Driving Speed: 0 – 15 km/h / 0 – 9 mph
