Specifications:
| Model No. | 5230040 | 5240040 |
| Description: | Terra Rake 350 – Folding | Terra Rake 460- Folding |
| Working Width: | 3.5m | 4.6m |
| Weight: | 560 kg | 660 kg |
| Tractor HP (min): | 40 | 60 |
Key Features:
Effective Thatch Removal
At travel speeds of 10 to 15 km/h, the parallelogram-guided scarifying tines vibrate aggressively to lift and remove thatch, placing it on the surface for easy collection.
Optimised Tine Arrangement
Four rows of tines ensure blockage-free scarification between individual tines, delivering consistent results across the entire working width.
Hydraulic Folding Mechanism
The two-part unit is easily moved from working to transport position via hydraulic cylinders, making it safe and simple to fold for transport or storage.
Wide Working Widths
Available in 3.50 m and 4.60 m working widths, the foldable design provides high coverage efficiency without sacrificing precision.
Durable Construction
Built for heavy-duty, continuous use, the Terra Rake – Folding combines rugged stability with long-lasting performance, ideal for professional turf maintenance.
Tractor Compatibility
Designed for rear 3-point linkage, it can be integrated easily with a range of tractors for flexible operation.
